60xx series

Bearing Number	d mm	D mm	H mm
6000	10	26	8
6001	12	28	8
6002	15	32	9
6003	17	35	10
6004	20	42	12
6005	25	47	12
6006	30	55	13
6007	35	62	14
6008	40	68	15
6009	45	75	16
6010	50	80	16
6011	55	90	18
6012	60	95	18
6013	65	100	18
6014	70	110	20
6015	75	115	20
6016	80	125	22
6017	85	130	22
6018	90	140	24
6019	95	145	24
6020	100	150	24
6021	105	160	26
6022	110	170	28
6024	120	180	28
6026	130	200	33
6028	140	210	33
6030	150	225	35
6032	160	240	38

62xx series

Bearing Number	d mm	D mm	H mm
6201	12	32	10
6202	15	35	11
6203	17	40	12
6204	20	47	14
6205	25	52	15
6206	30	62	16
6207	35	72	17
6208	40	80	18
6209	45	85	19
6210	50	90	20
6211	55	100	21
6212	60	110	22
6213	65	120	23
6214	70	125	24
6215	75	130	25
6216	80	140	26
6217	85	150	28
6218	90	160	30
6219	95	170	32
6220	100	180	34
6221	105	190	36
6222	110	200	38
6224	120	215	40
6225	130	230	40
6226	130	230	40
6228	140	250	42
6230	150	270	45
6232	160	290	48
6234	170	310	52
6236	180	320	52
6238	190	340	55
6240	200	360	58

63xx series

Bearing Number	d mm	D mm	H mm
6300	10	35	11
6301	12	37	12
6302	15	42	13
6303	17	47	14
6304	20	52	15
6305	25	62	17
6306	30	72	19
6307	35	80	21
6308	40	90	23
6309	45	100	25
6310	50	110	27
6311	55	120	29
6312	60	130	31
6313	65	140	33
6314	70	150	35
6315	75	160	37
6316	80	170	39
6317	85	180	41
6318	90	190	43
6319	95	200	45
6320	100	215	47
6321	105	225	49
6322	110	240	50
6324	120	260	55
6326	130	260	58
6328	140	300	62
6330	150	320	65
6332	160	344	68
6334	170	360	72
6336	180	380	75
6338	190	400	78
6340	200	420	80

64xx series

Bearing Number	d mm	D mm	B mm
6403	17	62	17
6404	20	72	19
6405	25	80	21
6406	30	90	23
6407	35	100	25
6408	40	110	27
6409	45	120	29
6410	50	130	31
6411	55	140	33
6412	60	150	35
6413	65	160	37
6414	70	180	42
6415	75	190	45
6416	80	200	48
6417	85	210	52
6418	90	225	54
6420	100	250	58
6422	110	280	65
6426	130	340	78

67xx series

Bearing Number	d mm	D mm	B mm
6700	10	15	4
6701	12	18	4
6702	15	21	4
6703	17	23	4
6704	20	27	4
6705	25	32	4
6706	30	37	4
6707	35	44	5
6708	40	50	6
6709	45	55	6
6710	50	62	6
6711	55	68	7

68xx series

Bearing Number	d mm	D mm	B mm
6800	10	19	5
6801	12	21	5
6802	15	24	5
6803	17	26	5
6804	20	32	7
6805	25	37	7
6806	30	42	7
6807	35	47	7
6808	40	52	7
6809	45	58	7
6810	50	65	7
6811	55	72	9
6812	60	78	10
6813	65	85	10
6814	70	90	10
6815	75	95	10
6816	80	100	10
6817	85	110	13
6818	90	115	13
6819	95	120	13
6820	100	125	13
6821	105	130	13
6822	110	140	16
6824	120	150	16
6826	130	165	18

British deep groove ball

Bearing Number	d mm/inch	D mm/inch	W mm/inch
1601	4.763 .1875	17.463 .6875	★6.350 .2500
1602	6.350 .2500	17.463 .6875	★6.350 .2500
1603	7.938 .3125	22.225 .8750	△7.144 .2812
1604	9.525 .3750	22.225 .8750	△7.144 .2812
1605	7.938 .3125	23.019 .9062	7.938 .3125
1606	9.525 .3750	23.019 .9062	7.938 .3125
1607	11.113 .4375	23.019 .9062	7.938 .3125
1614	9.525 .3750	28.575 1.1250	9.525 .3750
1615	11.113 .4375	28.575 1.1250	9.525 .3750
1616	12.700 .5000	28.575 1.1250	9.525 .3750
1620	11.113 .4375	34.925 1.3750	11.113 .4375
1621	12.700 .5000	34.925 1.3750	11.113 .4375
1622	14.288 .5625	34.925 1.3750	11.113 .4375
1623	15.875 .6250	34.925 1.3750	11.113 .4375
1628	15.875 .6250	41.2751.6250	12.700 .5000
1630	19.050 .7500	41.2751.6250	12.700 .5000
1633	15.875 .6250	44.4501.7500	12.700 .5000
1635	19.050 .7500	44.4501.7500	12.700 .5000

Double row deep groove ball

Bearing Number	d mm	D mm	B mm
4200	10	30	14
4201	12	32	14
4202	15	35	14
4203	17	40	16
4204	20	47	16
4205	25	52	18
4206	30	62	20
4207	35	72	23
4208	40	80	23
4228	45	85	23
4210	50	90	23
4301	12	37	17
4302	15	42	17
4303	17	47	19
4304	20	52	21
4305	25	62	24
4306	30	72	27
4307	35	80	31
4308	40	90	33
4309	45	100	36
4310	50	110	40

Thickened deep groove ball

Bearing Number	d mm inch		D mm inch		B mm inch
62200	10	0.3937	30	1.1811	14	0.5512
62201	12	0.4724	32	1.2598	14	0.5512
62202	15	0.5906	35	1.378	14	0.5512
62203	17	0.6693	40	1.5748	16	0.6299
62204	20	0.7874	47	1.8504	18	0.7086
62205	25	0.9843	52	2.1645	18	0.7086
62206	30	1.1811	62	2.4409	20	0.7874
62207	35	1.3779	72	2.8346	23	0.9055
62208	40	1.5748	80	3.1496	23	0.9055
62209	45	1.7716	85	3.3464	23	0.9055
62210	50	1.965	90	3.5464	23	0.9055
62211	55	2.1653	100	3.937	25	0.9843
62212	60	2.362	110	4.3307	28	1.1024
62213	65	2.559	120	4.7244	31	1.2205
62214	70	2.7559	125	4.9213	31	1.2205
62215	75	2.9528	130	5.1181	31	1.2205
62216	80	3.1496	140	5.7087	33	1.2992
62217	85	3.3454	150	5.9055	36	1.4173
62218	90	3.5433	160	6.2996	40	1.5748
62219	95	3.7402	170	6.6929	43	1.6926
62220	100	3.937	180	7.0866	46	1.811
62300	10	0.3937	35	1.378	17	0.6693
62301	12	0.4724	37	1.4567	17	0.6693
62302	15	0.5906	42	1.6535	17	0.6693
62303	17	0.6693	47	1.8504	19	0.748
62304	20	0.7874	52	2.0472	21	0.8267
62305	25	0.9843	62	2.4409	24	0.9448
62306	30	1.1811	72	2.8346	27	1.063
62307	35	1.3779	80	3.1496	31	1.2204
62308	40	1.5748	90	3.5433	33	1.2992
62309	45	1.7716	100	3.937	36	1.4173
62310	50	1.965	110	4.3307	40	1.5748
62311	55	2.1653	120	4.7244	43	1.6929
62312	60	2.362	130	5.1181	46	1.811
62313	65	2.559	140	5.7187	48	1.8898
62314	70	2.7559	150	5.9055	51	2.0078
62315	75	2.9528	160	6.2992	55	2.1654
62316	80	3.1496	170	6.6929	58	2.2835
62317	85	3.3454	180	7.0866	60	2.362
62318	90	3.5433	190	7.1803	64	2.5197
62319	95	3.7402	200	7.874	67	2.6378

88xxx series

Bearing Number			d mm inch		D mm inch		B mm inch
8501	87501	88501	12	0.4724	32	1.2598	12.7	0.5
8013	87013	88013	13	0.5118	32	1.2598	12.7	0.5
8014	87014	88014	14	0.5512	35	1.378	12.7	0.5
8502	87502	88502	15	0.5906	35	1.378	12.7	0.5
8016	87016	88016	16	0.6299	35	1.378	12.7	0.5
8602	88602	88602	15	0.5906	42	1.6535	15	0.5906
8503	88503	88503	17	0.6693	40	1.5748	14.288	0.5625
8603	88603	88603	17	0.6693	47	1.8504	16	0.6299
8504	88504	88504	20	0.7874	47	1.8504	15.875	0.625
8604	88604	88604	20	0.7874	52	2.0472	19	0.748
8505	88505	88505	25	0.9843	52	2.0472	15.875	0.625
8605	88605	88605	25	0.9843	62	2.4409	21	0.8268
8506	88506	88506	30	1.1811	62	2.4409	20	0.7874
8606	88606	88606	30	1.1811	72	2.8346	23	0.9055
8507	88507	88507	35	1.378	72	2.8346	21	0.8268
8607	88607	88607	35	1.378	80	3.1496	25	0.9843
8508	88508	88508	40	1.5748	80	2.1496	24	0.9449
8608	88608	88608	40	1.5748	90	3.5433	27	1.063
8509	88509	88509	45	1.7717	85	3.6465	24	0.9449
8609	88609	88609	45	1.7717	100	3.937	30	1.1811
8510	88510	88510	50	1.9615	90	3.5433	26	1.0236
8511	88511	88511	55	2.5614	100	3.937	27	1.063

TM-SC series

Bearing Number	d mm	D mm	B mm
TM-SC08804CM25	40	80	17
TM-SC0988EX1X2/85CM17	45	85	17
TM-SC07A7CS42-1	35	72	15
TM-SC07A87CS26	35	72	15
3TM-SC05B897	26	72	15.5
3TM-SC05B97	26	72	15.5
TM-SC1467CS42	70	100	12
TM-SC04C27CS32	20	60	13
TM-SC08B04CM25 PX1	40	81	17
TM-SC04C23CS12PX1	22	56	15
TM-SC06B42	25	72	18
TM-SC08A76CS20	40	90	20
3TM-SC08A76CS20PX1	40	90	20
TM-SC08A76CS20PX1	40	90	20

B series

Bearing Number	Size mm
B20-151	20x52x16
B20-160	20x52x12
B20-161	20x52x14
B20-49NR	20x55x15
B22-19	22x62x17
B23-9	23x42x7
B24Z-2URN	25x63x17
B25-109	25x52x15
B25-10BC3	25x65x17
B25-139	25x68x18
B25-145	25x63x17
B25-147	25x62x19
B25-157	25x68x18
B25-163	25x60x19/27
B25-164ZNXC3	25x60x17/25
B25-166	25x67x26
B25-185V	25x61x20
B25-19	25x63x18
B25-198	25x63x18
B25-214	25X62X16
B25-224	25X62X16
B25-238	25X68X19
B25-238NX	25x68x19
B25-249	25x68x19
B25-254	25x52x22
B25-63DA2	25x63x18

Bearing Number	Size mm
B45-108	45X90x17
B45-130NX2UR	45X85X15
B49-3	49X90X19.7
B57Z-7	57.7X80X13
B58-1	58X104/108X21
B60-44	60X130X22/31
B60-57N	60x101x17.2
B67-1	67X92x13
B67Z-7	67.5X80X12/13
B75-55NX	75X110X18
B8-75ZZ	8X24X10/9
BD22-2ENX1	22X47X20.6
BD25-9	25X52X23.5
B8-74	8X22X11
BD17-29	17X52X22
BD25-49NX	25X60X27
BD29-2B	29X55X22.5
BD35-12B	35X64X37
BD35-15	35X65X26
BDZ27-1AUR	27X63X23
BDZ27-2NX	27X60X27
BDZ27-3N	27X63X28
BDZ38-1	38X68X26
BDZ45-1	45X79X26
BDZ56-2	56X84X23.5/25

Air conditioner bearings

Bearing Number	Size mm
45BG07S5G-2DST	45x72x32mm
45BD7532	45x72x32mm
45BD6820	45x68x20mm
45BD6420	45x64x20mm
40BD6830	40x68x30mm
40BGS39G-3DS	40x66x24mm
40BD6624	40x66x24mm
40BGS35G-2DS	40x62x24mm
40BD6224	40x62x24mm
40BG05S1DS	40x57x24mm
40BD5724	40x57x24mm
40BGS40G	40x55x24mm
40BD5524	40x55x24mm
38BD6224	38x62x24mm
38BD5417	38x54x17mm
35BD6228	35x62x28mm
35BD6224	35x62x24mm
30BD461816	304618/16mm
30BD4718	304718mm
30BD472118	304721/18mm
30BD4722	304722mm
30BD5220	305220mm
30BD5222	305222mm
30BD5523	305523mm
30BD5526	305526mm
30BD6227	306227mm
32BD4718	324718mm
32BD522015	325220/15mm
32BD5523	325523mm
35BD5020	355020mm
35BD5220	355220mm
35BD5222	355222mm
35BD5223	355223mm
35BD5520	355520mm
35BD6221	356221mm
35BD6224	356224mm
35BD6228	356228mm
38BD5417	385417mm
38BD6224	386224mm
40BD5524	405524mm
40BD5724	405724mm
40BD572420	405724/20mm
40BD62206	406220.625mm
40BD6224206	406224*20.625mm
40BD6224	406224mm
40BD6624	406624mm
40BD6830	406830mm
45BD6420	456420mm
45BD6820	456820mm
45BD7532	457532mm
30BD5222	30X52X22mm
35BD5020DDU	35X50X20mm
35BD5212DDU	35X52X12mm
EP35BD354820	35X48X20mm
30BD4720	30X47X20mm
