12xx series
Bearing Number | d mm | D mm | B mm |
1200 | 10 | 30 | 9 |
1202 | 35 | 11 | |
1203 | 17 | 40 | 12 |
1204 | 20 | 47 | 14 |
1205 | 25 | 52 | 15 |
1206 | 30 | 62 | 16 |
1207 | 35 | 72 | 17 |
1208 | 40 | 80 | 18 |
1209 | 45 | 85 | 19 |
1210 | 50 | 90 | 20 |
1212 | 60 | 110 | 22 |
1213 | 65 | 120 | 23 |
1214 | 70 | 125 | 24 |
1215 | 75 | 130 | 25 |
1216 | 80 | 140 | 26 |
1217 | 85 | 150 | 28 |
1218 | 90 | 160 | 30 |
1219 | 95 | 170 | 32 |
1220 | 100 | 180 | 34 |
1221 | 105 | 190 | 36 |
13xx series
| Bearing Number | d mm | D mm | B mm |
| 1300 | 10 | 35 | 11 |
| 1301 | 12 | 37 | 12 |
| 1302 | 15 | 42 | 13 |
| 1303 | 17 | 47 | 14 |
| 1304 | 20 | 52 | 15 |
| 1305 | 25 | 62 | 17 |
| 1306 | 30 | 72 | 19 |
| 1307 | 35 | 80 | 21 |
| 1308 | 40 | 90 | 23 |
| 1309 | 45 | 100 | 25 |
| 1310 | 50 | 110 | 27 |
22xx series
| Bearing Number | d mm | D mm | B mm |
| 2200 | 10 | 30 | 14 |
| 2201 | 12 | 32 | 14 |
| 2202 | 15 | 35 | 14 |
| 2203 | 17 | 40 | 16 |
| 2204 | 20 | 47 | 18 |
| 2205 | 25 | 52 | 18 |
| 2208 | 40 | 80 | 23 |
| 2209 | 45 | 85 | 23 |
| 2210 | 50 | 90 | 23 |
| 2211 | 55 | 100 | 25 |
| 2212 | 60 | 110 | 28 |
| 2213 | 65 | 120 | 31 |
| 2214 | 70 | 125 | 31 |
| 2215 | 75 | 130 | 31 |
| 2216 | 80 | 140 | 33 |
| 2217 | 85 | 150 | 36 |
| 2218 | 90 | 160 | 40 |
| 2220 | 100 | 180 | 46 |
| 2221 | 105 | 190 | 50 |
| 2222 | 110 | 200 | 53 |
23xx series
| Bearing Number | d mm | D mm | B mm |
| 2300 | 10 | 35 | 17 |
| 2301 | 12 | 37 | 17 |
| 2302 | 15 | 42 | 17 |
| 2303 | 17 | 47 | 19 |
| 2304 | 20 | 52 | 21 |
| 2305 | 25 | 62 | 24 |
| 2306 | 30 | 72 | 27 |
| 2307 | 35 | 80 | 31 |
| 2308 | 40 | 90 | 33 |
| 2309 | 45 | 100 | 36 |
| 2310 | 50 | 110 | 40 |
| 2311 | 55 | 120 | 46 |
| 2312 | 60 | 130 | 46 |
| 2313 | 65 | 140 | 48 |
| 2314 | 70 | 150 | 51 |
| 2315 | 75 | 160 | 55 |
| 2316 | 80 | 170 | 58 |
| 2317 | 85 | 160 | 60 |
| 2318 | 90 | 190 | 64 |
| 2319 | 95 | 200 | 67 |
| 2320 | 100 | 215 | 73 |
| 2321 | 105 | 225 | 77 |
| 2322 | 110 | 240 | 80 |
1xxxK+1xxxH series
| Bearing Number | d mm | D mm | B mm |
| 1203K+H203 | 11203 | 17 | 47 |
| 1204K+H204 | 11204 | 20 | 47 |
| 1205K+H205 | 11205 | 25 | 52 |
| 1206K+H206 | 11206 | 30 | 62 |
| 1207K+H207 | 11207 | 35 | 72 |
| 1208K+H208 | 11208 | 40 | 80 |
| 1209K+H209 | 11209 | 45 | 85 |
| 1210K+H210 | 11210 | 50 | 90 |
| 1211K+H211 | 11211 | 55 | 100 |
| 1212K+H212 | 11212 | 60 | 110 |
| 1213K+H213 | 11213 | 65 | 130 |
| 1214K+H214 | 11214 | 70 | 140 |
| 1215K+H215 | 11215 | 75 | 150 |
| 1216K+H216 | 11216 | 80 | 160 |
| 1217K+H217 | 11217 | 85 | 170 |
| 1218K+H218 | 11218 | 90 | 180 |
| 1220K+H220 | 11220 | 100 | 200 |
| 1304K+H304 | 11303 | 20 | 52 |
| 1305K+H305 | 11304 | 20 | 62 |
| 1306K+H306 | 11305 | 30 | 72 |
| 1307K+H307 | 11306 | 35 | 80 |
| 1308K+H308 | 11307 | 40 | 90 |
| 1309K+H309 | 11308 | 45 | 100 |
22xxK+Hxxx series
| Bearing Number | d mm | D mm | B m | |
| 2204K+H304 | 11503 | 17 | 47 | 18 |
| 2205K+H305 | 11504 | 20 | 52 | 18 |
| 2206K+H306 | 11505 | 25 | 62 | 20 |
| 2207K+H307 | 11506 | 30 | 72 | 23 |
| 2208K+H308 | 11507 | 35 | 80 | 23 |
| 2209K+H309 | 11508 | 40 | 85 | 23 |
| 2210K+H310 | 11509 | 45 | 90 | 23 |
| 2211K+H311 | 11510 | 50 | 100 | 25 |
| 2212K+H312 | 11511 | 55 | 110 | 28 |
| 2213K+H313 | 11512 | 60 | 120 | 31 |
| 2215K+H315 | 11513 | 65 | 130 | 31 |
| 2216K+H316 | 11514 | 70 | 140 | 33 |
| 2217K+H317 | 11515 | 75 | 150 | 36 |
| 2218K+H318 | 11516 | 80 | 160 | 40 |
| 2219K+H319 | 11517 | 85 | 170 | 45 |
| 2220K+H320 | 11518 | 90 | 180 | 46 |
